SB-PCV Series

Applications: Tight Isolation for Pressure Control

Temperature and Pressure Class: ANSI 3500# 4500# Class

Size: 2.5"– 4"

Special design feature:

Body is forged, Standard material is A182 F22 F91, F92 is option.
        Ball and Seat are patented Square Bore
        Ball and Seat are mate-lapped by hand to 100% sealing contact
        Open/Close is double indicating
        Anti-blow-out of stem
        Connection is Butt Weld or with Flange

Field:

Power Plant
        Nuclear Plant
        Process Boiler system

Flow Medium:

Steam
